Product Introduction

• CFB-901 is a highly integrated module that supports NB IoT and Bluetooth in one standard communication module. NB IoT supports the full frequency range of 698-2180MHz and initially supports Band 1, 3, 5, 8, and 20 bands. Supports E-SIM function. It is mainly used for low-power data transmission services and complies with the NB IoT radio communication protocol (3GPP Release-13/14/15) standard. Bluetooth supports the BLE5.0 standard.
• The CFB-901 module can be connected to numerous terminal devices, embedded with TCP/UDP/CoAP/MQTT/DTLS/DTLS+and other data transmission protocols. It is the first module to support 3GPP Rel13/14/15 and extended AT commands. Support base station positioning. It can almost meet the application needs of all IoT applications. For example, intelligent measurement, shared bicycles, intelligent parking, smart cities, security, asset tracking, smart appliances, agriculture and environmental monitoring, etc.
• CFB-901 supports secondary development and has 19 GPIOs, which can support SPIx1, UARTx3, I2Cx2, ADCx2, and PWMx1 standard interfaces.
• CFB-901 adopts LCC chip packaging and has a 20mm thickness × 16mm × A super small size of 2.2mm.
• The CFB-901 module adopts power-saving technology, with a power consumption of approximately 1uA in power-saving mode (PSM).
•

Main advantages

Performance
